TB1662-024L Universal 5-Wire Square Plug Power Running Board Motor Front Left Driver Side with 135mm Short-Length Wiring Harness Heavy Duty Standalone Electric Side Step Actuator

Product Specifications & Placement:
- Factory Identification Reference: TB1662-024L
- Plug Layout: 5-Wire / 5-Pin Square Female Terminal Configuration

Operating temperature and humidity range: Temperature: -20℃ to +65℃; Humidity: 45% to 75%.
Storage temperature and humidity range: Temperature: -10 to 40℃, Humidity: 75% (maximum).
Protection level IPX7
Load: 5Nm, Speed: 14 ± 1 RPM; Current ≤ 5.0A
Load: 20Nm, Speed: 8 ± 1 RPM; Current ≤ 12A
Brake torque: Torque ≥ 50 N.m; Current ≤ 28A
Output (Output) shaft speed: 15 RPM ± 1 RPM

view more Inquiry
TB1662-023R Universal 5-Wire Square Plug Power Running Board Motor Front Right Passenger Side with 265mm Extra-Long Wiring Harness Heavy Duty Standalone Electric Side Step Actuator

Product Specifications & Placement:
- Factory Identification Reference: TB1662-023R
- Plug Layout: 5-Wire / 5-Pin Square Female Terminal Configuration

Operating temperature and humidity range: Temperature: -20℃ to +65℃; Humidity: 45% to 75%.
Storage temperature and humidity range: Temperature: -10 to 40℃, Humidity: 75% (maximum).
Protection level IPX7
Load: 5Nm, Speed: 14 ± 1 RPM; Current ≤ 5.0A
Load: 20Nm, Speed: 8 ± 1 RPM; Current ≤ 12A
Brake torque: Torque ≥ 50 N.m; Current ≤ 28A
Output (Output) shaft speed: 15 RPM ± 1 RPM

view more Inquiry
TB1662-023L Universal 5-Wire Square Plug Power Running Board Motor Front Left Driver Side with 265mm Extra-Long Wiring Harness Heavy Duty Standalone Electric Side Step Actuator

Product Specifications & Placement:
- Factory Identification Reference: TB1662-023L
- Plug Layout: 5-Wire / 5-Pin Square Female Terminal Configuration

Operating temperature and humidity range: Temperature: -20℃ to +65℃; Humidity: 45% to 75%.
Storage temperature and humidity range: Temperature: -10 to 40℃, Humidity: 75% (maximum).
Protection level IPX7
Load: 5Nm, Speed: 14 ± 1 RPM; Current ≤ 5.0A
Load: 20Nm, Speed: 8 ± 1 RPM; Current ≤ 12A
Brake torque: Torque ≥ 50 N.m; Current ≤ 28A
Output (Output) shaft speed: 15 RPM ± 1 RPM

view more Inquiry
TB1662-011R Universal 5-Wire Square Plug Power Running Board Motor Front Right Passenger Side with 200mm Extended Wiring Harness Heavy Duty Standalone Electric Side Step Actuator

Product Specifications & Placement:
- Factory Identification Reference: TB1662-011R
- Plug Layout: 5-Wire / 5-Pin Square Female Terminal Configuration

Operating temperature and humidity range: Temperature: -20℃ to +65℃; Humidity: 45% to 75%.
Storage temperature and humidity range: Temperature: -10 to 40℃, Humidity: 75% (maximum).
Protection level IPX7
Load: 5Nm, Speed: 14 ± 1 RPM; Current ≤ 5.0A
Load: 20Nm, Speed: 8 ± 1 RPM; Current ≤ 12A
Brake torque: Torque ≥ 50 N.m; Current ≤ 28A
Output (Output) shaft speed: 15 RPM ± 1 RPM

view more Inquiry
TB1662-011L Universal 5-Wire Square Plug Power Running Board Motor Front Left Driver Side with 200mm Extended Wiring Harness Heavy Duty Standalone Electric Side Step Actuator

Product Specifications & Placement:
- Factory Identification Reference: TB1662-011L
- Plug Layout: 5-Wire / 5-Pin Square Female Terminal Configuration

Operating temperature and humidity range: Temperature: -20℃ to +65℃; Humidity: 45% to 75%.
Storage temperature and humidity range: Temperature: -10 to 40℃, Humidity: 75% (maximum).
Protection level IPX7
Load: 5Nm, Speed: 14 ± 1 RPM; Current ≤ 5.0A
Load: 20Nm, Speed: 8 ± 1 RPM; Current ≤ 12A
Brake torque: Torque ≥ 50 N.m; Current ≤ 28A
Output (Output) shaft speed: 15 RPM ± 1 RPM

view more Inquiry
TB1661-005R Universal 5-Wire Inside 6-Pin Square Plug Power Running Board Motor Front Right Passenger Side Heavy Duty Standalone Electric Side Step Actuator

Product Specifications & Placement:
- Factory Identification Reference: TB1661-005R
- Plug Layout: 5-Wire Configuration Inside a 6-Pin/6-Hole Square Female Terminal Casing

Operating temperature and humidity range: Temperature: -20℃ to +65℃; Humidity: 45% to 75%.
Storage temperature and humidity range: Temperature: -10 to 40℃, Humidity: 75% (maximum).
Protection level IPX7
Load: 5Nm, Speed: 14 ± 1 RPM; Current ≤ 5.0A
Load: 20Nm, Speed: 8 ± 1 RPM; Current ≤ 12A
Brake torque: Torque ≥ 50 N.m; Current ≤ 28A
Output (Output) shaft speed: 15 RPM ± 1 RPM

view more Inquiry
